This is the same port as the OEM hose was removed from in step #7. Attach short end of return hose to the port on back of upper intake plenum (as shown). Attach loose end of feed hose to the side banjo fitting barb on catch can. Note: If your plenum does not have a stud in this location, please use the supplied M6-1.0 x 10mm flanged bolt to secure the bracket in place. Thread bolt from previous step back into the same mounting hole securing the catch can assembly in place. Place catch can assembly onto stud next to bolt removed in step #12. Remove the bolt securing the hardline to the back right of the upper intake plenum (circled below). Thread a bolt into each slot on catch can (as shown). Place another crush washer on the end of each bolt. Then place each bolt through a banjo fitting barb. Place a crush washer on each banjo fitting bolt. Be sure the outer screw under the access hole in the top of the bracket is accessible. Attach bracket to top of catch can using (3) M4 screws and the supplied 2.5mm Ball-End Hex Screwdriver in the same orientation as pictured below. Locate catch can, catch can backet, (3) M4 screws, and (1) 2.5mm Ball-End Hex Screwdriver. Route the hose similar to how the OEM one was just removed, under the throttle body connector toward the rear of the upper intake plenum. Attach longer side to PCV port on passenger side valve cover where OEM hose was removed in step #7, secure with hose clamp. Locate new Z1 Oil Catch Can Feed Hose (longer of the two supplied hoses). Slightly lift the plenum in order to pull the hose out of its slot (as shown). Note: The hose runs underneath the upper intake plenum near where the throttle body connects. Loosen hose clamps and remove the OEM PCV hose that runs from the passenger side valve cover to the rear of the upper intake plenum (shown in red below). Remove (8) bolts securing upper intake manifold/plenum to engine. Disconnect the connector located at the back left of the upper intake manifold/plenum (as shown). Remove (4) bolts securing throttle body to engine. Loosen clamp and remove the passenger air intake pipe from the passenger side throttle body. Remove the (6) bolts and (2) nuts securing strut tower bar to vehicle.
2008 BMW 335I INSTALL OIL CATCH CAN MANUAL
Place the transmission in Park position (or in Reverse gear if equipped with a manual transmission).
BEFORE YOU BEGIN: Remove contents from the Z1 Motorsports 350Z / G35 (VQ35HR) Baffled Oil Catch Can Kit and verify that ALL necessary hardware is present. Only operate drivetrain in safe space and well-ventilated areas. Always keep limbs and parts away from moving drivetrain parts. Always use properly rated jack stands when working under your vehicle. Always turn the ignition to the OFF position and disconnect the NEGATIVE battery terminal. If using any fluids, chemicals, or solvents, a respirator is recommended. P a g e 1 Part # IM Revision IR ABĢ PARTS INCLUDED: Item Quantity Description 1 1 Z1 Universal Catch Can 2 2 Banjo Fitting 3 2 Bango Bolt 4 1 Catch Can Bracket 5 1 Catch Can Return Hose 6 1 Catch Can Feed Hose 7 4 Crush Washer 8 3 M4-0.7 x 8mm Screw 9 4 Hose Clamp 10 1 M6 Lock Nut 11 1 M6-1.0 x 10mm Bolt mm Ball-End Hex Screwdriver TOOLS REQUIRED: Ratchet Pliers 8mm Allen Wrench/Socket 10mm Socket/Wrench 12mm Socket Flat-Head Screwdriver 2.5mm Ball-End Hex Screwdriver (supplied) SAFETY REQUIREMENTS: Always wear safety glasses and any necessary protective garments.
2008 BMW 335I INSTALL OIL CATCH CAN PROFESSIONAL
If you have any questions regarding installation or the various components included with the Z1 Motorsports 350Z / G35 (VQ35HR) Baffled Oil Catch Can Kit, consult with a Professional Mechanic or contact Z1 Motorsports for more information. Please observe and abide by any Warning or Caution labels placed on the various components and tools used when servicing your vehicle. WARNING! Extreme caution should be taken when performing maintenance or performance upgrades to your vehicle.
.jpg "2008 bmw 335i install oil catch can")
If unfamiliar with any of the concepts outlined in this instruction, we recommend the installation be completed by a qualified professional. The installer must have a thorough knowledge of automotive systems operation. 1 Z1 350Z G35 (vq35hr) Baffled oil Catch CAN Kit INSTALLATION MANUAL This Installation Manual is intended for the following models: Nissan 350Z Infiniti G35 Sedan PROLOGUE: Study these instructions completely before proceeding to assembly.
